F350 on a 2 post hoist

Thread Tools

Search this Thread

  #1
Old 01-10-2009, 12:40 PM
Hummin Cummins's Avatar
Diesel Wrench
Thread Starter
Join Date: Nov 2008
Location: ND
Posts: 574
Received 29 Likes on 27 Posts
Default F350 on a 2 post hoist

I want to put my dads 05 F350 on the hoist to give it a oil change and a look over. I just recently got a 2 post hoist. Where do I put the front arms? I don't know if lifting on the back of the control arms is a good idea the only other place is the body mount.
Does any one know for sure???

  #2
Old 01-10-2009, 01:12 PM
DIRTYMAX2004's Avatar
Diesel Bomber
Join Date: Mar 2007
Location: New Salem, ND
Posts: 1,192
Received 81 Likes on 42 Posts
Default

contact whoever made the lift

  #3
Old 01-10-2009, 01:15 PM
Hummin Cummins's Avatar
Diesel Wrench
Thread Starter
Join Date: Nov 2008
Location: ND
Posts: 574
Received 29 Likes on 27 Posts
Default

Originally Posted by power95
contact whoever made the lift
I would but their closed today.

  #4
Old 01-10-2009, 01:47 PM
DIRTYMAX2004's Avatar
Diesel Bomber
Join Date: Mar 2007
Location: New Salem, ND
Posts: 1,192
Received 81 Likes on 42 Posts
Default

call some repair shop that has a 2 post lift

  #5
Old 01-10-2009, 03:53 PM
Hummin Cummins's Avatar
Diesel Wrench
Thread Starter
Join Date: Nov 2008
Location: ND
Posts: 574
Received 29 Likes on 27 Posts
Default

I lifted the front by the back of the control arms and the back by the spring shackels. Seemed to be ok

  #6
Old 01-10-2009, 04:28 PM
scottsjeeprolet's Avatar
Go RAVENS!!!!!!!!!
Join Date: Mar 2007
Location: Kingsville, MD
Posts: 1,145
Received 229 Likes on 113 Posts
Default

Make sure it's at least a 10000# lift. My Rotary lift lifts mine no problem.
F350 on a 2 post hoist-camera-028.jpgF350 on a 2 post hoist-dtr-get-together-pics-4-1-07-008.jpg


Last edited by scottsjeeprolet; 01-10-2009 at 04:33 PM.
  #7
Old 01-10-2009, 08:10 PM
Hummin Cummins's Avatar
Diesel Wrench
Thread Starter
Join Date: Nov 2008
Location: ND
Posts: 574
Received 29 Likes on 27 Posts
Default

I got a 15K Challanger

  #8
Old 01-10-2009, 10:11 PM
Mr. Miyagi's Avatar
Diesel Bomber
Join Date: Mar 2007
Location: Olympic Peninsula
Posts: 2,564
Received 285 Likes on 193 Posts
Default

Do you have an owner's/operator's/maintenance manual that comes with the lift?

Does it have extensions for the kick ups?

  #9
Old 01-11-2009, 10:25 AM
RSWORDS's Avatar
BOMBARDIER

Join Date: Mar 2007
Location: Gloucester, VA
Posts: 11,159
Received 918 Likes on 537 Posts
Default

Front, use the rear of the front radius arms just forward where they mount to the frame, there is a raised up contact on the bottom of the arm. You should not need any of the lift spacers unless your step bars hang real low
Rear, try to get them as far back where the frame straightens out and becomes flat but in front of the rear spring hangers. You will need to use most of the spacers in the back to get the truck level.

  #10
Old 01-11-2009, 11:35 AM
Hummin Cummins's Avatar
Diesel Wrench
Thread Starter
Join Date: Nov 2008
Location: ND
Posts: 574
Received 29 Likes on 27 Posts
Default

Originally Posted by RSWORDS
Front, use the rear of the front radius arms just forward where they mount to the frame, there is a raised up contact on the bottom of the arm. You should not need any of the lift spacers unless your step bars hang real low
Rear, try to get them as far back where the frame straightens out and becomes flat but in front of the rear spring hangers. You will need to use most of the spacers in the back to get the truck level.
Sounds like I did the front right is their any harm by lifting on the spring hangers?
