JW about injectors???

Thread Tools

Search this Thread

  #21
Old 04-13-2011, 10:00 AM
95powersmoker's Avatar
BOMBARDIER
Join Date: Mar 2010
Location: Ellensburg, WA
Posts: 2,959
Received 187 Likes on 161 Posts
Default
Originally Posted by CSIPSD
https://www.dieselbombers.com/99-03-...tml#post527811


clicky linky... Guys... Check that sticky file at the top of the 7.3 area... Lots of good information there and I add more as soon as I can dig it up!!!
Joe, I couldn't get that link to work last night... Nor does it work right now...

Reply Like
  #22
Old 04-13-2011, 10:04 AM
CSIPSD's Avatar
Diesel Bomber
Join Date: Sep 2007
Location: Bend OR
Posts: 7,638
Received 638 Likes on 482 Posts
Default
Originally Posted by 95powersmoker
Joe, I couldn't get that link to work last night... Nor does it work right now...

Gurrrr.... Calling David right now...

David is working on it... I'll get it fixed as soon as I can.

Last edited by CSIPSD; 04-13-2011 at 10:10 AM.
Reply Like
  #23
Old 04-13-2011, 10:23 PM
Bigred7.3's Avatar
Diesel Enthusiast
Join Date: Aug 2010
Location: Davie, fl
Posts: 392
Received 3 Likes on 3 Posts
Default
do i have to take the motor apart inorder to findout if i have pmrs or can i find out sanother way

Reply Like
  #24
Old 04-13-2011, 10:41 PM
CSIPSD's Avatar
Diesel Bomber
Join Date: Sep 2007
Location: Bend OR
Posts: 7,638
Received 638 Likes on 482 Posts
Default
You do not have to take anything but a small 5/16" plug out... Give me a day or so, I will get the link back up.

I called David today and he was suprised it was not working...

Reply Like
  #25
Old 04-13-2011, 10:47 PM
Bigred7.3's Avatar
Diesel Enthusiast
Join Date: Aug 2010
Location: Davie, fl
Posts: 392
Received 3 Likes on 3 Posts
Default
o ok, thanks csipsd, ill look at the link wen its back up

Reply Like
  #26
Old 04-14-2011, 11:36 AM
PHPDiesel's Avatar
Sponsor
Join Date: May 2010
Posts: 327
Received 26 Likes on 20 Posts
Default
Here's one of the holes:


This is where it's located (where the aftermarket filter hose goes in behind the oil filter):

Reply Like
The following 2 users liked this post by PHPDiesel:
95powersmoker (04-14-2011), CSIPSD (04-14-2011)
  #27
Old 04-14-2011, 12:10 PM
CSIPSD's Avatar
Diesel Bomber
Join Date: Sep 2007
Location: Bend OR
Posts: 7,638
Received 638 Likes on 482 Posts
Default
Thanks Cody...

So what you need to do is bump the motor over until you can see the bottom of a rod... You want to see a nut and stud... You dont want to see a bolt.

I have a PMR rod in the back of my truck, I'll get a pic after lunch and post it up.

Reply Like
  #28
Old 04-14-2011, 03:12 PM
PHPDiesel's Avatar
Sponsor
Join Date: May 2010
Posts: 327
Received 26 Likes on 20 Posts
Default
One that looks like this?

Reply Like
  #29
Old 04-14-2011, 04:07 PM
CSIPSD's Avatar
Diesel Bomber
Join Date: Sep 2007
Location: Bend OR
Posts: 7,638
Received 638 Likes on 482 Posts
Default
Well... Yours looks like a red X... Mine looks like this...


I'll load them on my webshots later today. Got to get to UPS...

Attached Thumbnails JW about injectors???-img_0001.jpg   JW about injectors???-img_0002.jpg   JW about injectors???-img_0003.jpg
Last edited by CSIPSD; 04-14-2011 at 04:12 PM.
Reply Like
The following users liked this post:
95powersmoker (04-14-2011)
  #30
Old 04-15-2011, 08:01 AM
PHPDiesel's Avatar
Sponsor
Join Date: May 2010
Posts: 327
Received 26 Likes on 20 Posts
Default
Plenty of pictures of broken ones on Google......


Reply Like
