5.9 Liter CR Dodge Cummins 03-07 Discussion of 5.9 Liter Dodge Cummins Diesels with Common Rail Injection

Belt Tensioner??

Thread Tools

Search this Thread

  #11
Old 10-07-2009, 09:44 PM
Heath's Avatar
Authorized Amsoil Dealer
Join Date: Mar 2007
Location: Mason City, Iowa
Posts: 1,122
Received 122 Likes on 95 Posts
Default

Mine just partially slipped off the power steering pulley today, just 2 rings over. Enough to make is squawk. NOt sure if something hit it to knock it over or whether I should be watching for the problems mentioned????

  #12
Old 07-25-2011, 12:47 PM
MrSandman818's Avatar
Diesel Fan
Join Date: Jun 2011
Location: The Pass, TX
Posts: 77
Received 1 Like on 1 Post
Default FML

Thanks for all the helpful info. I just got mine back from the body shop and they were freaking out because it ate 1 of the ribs of the belt. I told em dont worry she has 7 more to go. This is my new problem child. Had it for 3 weeks. 1 week in my possesion, the other 2 in the body shop, mechanic shop, driveline shop. Not a bad way to spend over 3k on the truck you just bought.

  #13
Old 07-27-2011, 11:13 AM
MrSandman818's Avatar
Diesel Fan
Join Date: Jun 2011
Location: The Pass, TX
Posts: 77
Received 1 Like on 1 Post
Default

Pulled the tensioner pulley off and swapped just the pulley itself. Cost $18 and the local shop had it. The one on the truck had a little bit of play in the bearings and the surface where the belt rides was worn in pretty good. On the back side right outside of the bearing it was melted from wobbling around too. I also noticed a lot of play on the idler pulley on the top, right in front of the valve cover. When the truck is running its dead straight. Oh well.

The old one is on the top.
Name:  005-10.jpg
Views: 151
Size:  32.6 KB

  #14
Old 07-27-2011, 06:15 PM
1993firstgennewbie's Avatar
Diesel Wrench
Join Date: Mar 2010
Location: denver colorado
Posts: 785
Received 43 Likes on 33 Posts
Default

replace the wole tetioner but be carful when you compress it theres a little peice of alluminum that can break off and ruin the part
