Turning your EBPV into an Exhaust Brake
#11
#12
#18
#20
tips and tricks that i encountered doing this mod.
1. The wire from the 4 wires marked center high lamp feed that do not lead to anything are dead wires. i taped in to the wire harness right behind the master cylinder on the driver’s side above your feet. (GREEN WIRE) check to see if it has power only when the brake is applied.
2. The wires coming off of the EBPV on the plug to the pedestal were not the same color as the directions depicted. Black with a white stripe and yellow with a red stripe. the yellow with red is the one to tap.
3. install another diode in the power supply so you do not short out what you are taping in to for power.
1. The wire from the 4 wires marked center high lamp feed that do not lead to anything are dead wires. i taped in to the wire harness right behind the master cylinder on the driver’s side above your feet. (GREEN WIRE) check to see if it has power only when the brake is applied.
2. The wires coming off of the EBPV on the plug to the pedestal were not the same color as the directions depicted. Black with a white stripe and yellow with a red stripe. the yellow with red is the one to tap.
3. install another diode in the power supply so you do not short out what you are taping in to for power.
