1999 K3500 Tempermental Throttle
#1
1999 K3500 Tempermental Throttle
Hello Diesel Bombers.
My first post comes to you abouta problem (regretably).
Just bought a rust free 1999 Chevy K3500 6.5TD with 122K on it.
Relocated Standadyne Heat Synk PMD
New Fuel Filter
New Lift Pump
The previous owner mentioned at times (usually when just cruising between 35-65MPH) and not when under load or "hammering" it, and not when idling, that the truck seems to have a wavey throttle, almost like a AC compressor engaging in a smaller car, or a transmission guessing weither to go into OD or not.
The tach seems to stay consistant, and then you'll feel a very minor loss of acceleration and then a very minor acceleration......it seems to do this and you barely loose 2-3 MPH however it is just somewhat aggrivating.
Anyone have any ideas?
My first post comes to you abouta problem (regretably).
Just bought a rust free 1999 Chevy K3500 6.5TD with 122K on it.
Relocated Standadyne Heat Synk PMD
New Fuel Filter
New Lift Pump
The previous owner mentioned at times (usually when just cruising between 35-65MPH) and not when under load or "hammering" it, and not when idling, that the truck seems to have a wavey throttle, almost like a AC compressor engaging in a smaller car, or a transmission guessing weither to go into OD or not.
The tach seems to stay consistant, and then you'll feel a very minor loss of acceleration and then a very minor acceleration......it seems to do this and you barely loose 2-3 MPH however it is just somewhat aggrivating.
Anyone have any ideas?
#2
welcome to DB
are you getting codes check all the grounds ad clean they play big part with these trucks
are at the back of motor right side on intake 2 or 3 wires there for the computer and also there are 3 ground strap right back there under the A/C Dryer one goes to the fire wall to back of the head and the other goes from fire wall to the frame make sure they good and then make sure your PMD thats on the heat sink is grounded to the top of the injector pump and then there one more at right battery on the fender
are you getting codes check all the grounds ad clean they play big part with these trucks
are at the back of motor right side on intake 2 or 3 wires there for the computer and also there are 3 ground strap right back there under the A/C Dryer one goes to the fire wall to back of the head and the other goes from fire wall to the frame make sure they good and then make sure your PMD thats on the heat sink is grounded to the top of the injector pump and then there one more at right battery on the fender
#3
welcome to DB
are you getting codes check all the grounds ad clean they play big part with these trucks
are at the back of motor right side on intake 2 or 3 wires there for the computer and also there are 3 ground strap right back there under the A/C Dryer one goes to the fire wall to back of the head and the other goes from fire wall to the frame make sure they good and then make sure your PMD thats on the heat sink is grounded to the top of the injector pump and then there one more at right battery on the fender
are you getting codes check all the grounds ad clean they play big part with these trucks
are at the back of motor right side on intake 2 or 3 wires there for the computer and also there are 3 ground strap right back there under the A/C Dryer one goes to the fire wall to back of the head and the other goes from fire wall to the frame make sure they good and then make sure your PMD thats on the heat sink is grounded to the top of the injector pump and then there one more at right battery on the fender
THANKS
#4
Yes you want to get that out from under ASP if it ant to late already that can also be your problem remember after you more to the front bumper you still want it grounded to top of the IP you can make your own harness if good at soldering
Oh check the wiring and plugs at trans make sure they are clean from dirty and the plug at fuel pedal all so
Oh check the wiring and plugs at trans make sure they are clean from dirty and the plug at fuel pedal all so
Last edited by Crazy; 01-16-2012 at 04:00 PM.
#5
Yes you want to get that out from under ASP if it ant to late already that can also be your problem remember after you more to the front bumper you still want it grounded to top of the IP you can make your own harness if good at soldering
Oh check the wiring and plugs at trans make sure they are clean from dirty and the plug at fuel pedal all so
Oh check the wiring and plugs at trans make sure they are clean from dirty and the plug at fuel pedal all so
---AutoMerged DoublePost---
Well I checked all the connections and grounds, they all look to be just fine.
It is tough to quite pinpoint when and how the diesel feels weird,but like I said, it's only when you're cruising and just going along your merry way between 35-55 or so MPH.
It almost feels like the transmission is going from OD to 3rd, but at an extremely fast rate, yet the engine RPM remains unchanged.......
If you didnt know better its as if there is a little gremlin just applying the E-Brake ever so slightly and about 5 times a second
Last edited by sweetguardian001; 01-17-2012 at 12:34 PM. Reason: Automerged Doublepost
#6
#8
ok I've been able to narrow down these symptoms for you all.
Scenario 1: Normal Driving.
Acceleration steady up to about 40-50MPH. No kicking, no nothing, runs beautiful. Get into OD, engine RPM about 1450-1600. Truck will drive steady at this speed for about 3-7 seconds, then you start to feel the loss of power and the subtle bucking of the truck. If the accelerator is depressed, you notice a 1-2 second pause, then the truck jumps to life and will accelerate flawlessly for as long as you want it to.
Scenario 2: 3rd vs.OD test.
Driving 40MPH, 1500RPM.
Shift truck manually into 3rd. Engine RPM 2000. Truck will hum like it is suppossed to and have zero issue for again, 3-7 seconds. Then you feel a drastic loss of power, and if the accelerator is left untouched, truck will drop 300-500RPM and not run quite right. If the accelerator is depressed once again, there is a slight delay, and then the truck jumps to life and truck will accelerate up to 2500+ RPM no problem.
I know it seems weird.....it only seems to happen UNDER 2000RPM and only when the truck either just shifted gears, and is in the lower RPM range for that gear....and there is a few second delay between the shift/coasting and the problem.
---AutoMerged DoublePost---
and i checked the lift pump.....you can hear it click on and run when truck is glowed, and when its idling you can feel it running.
Truck idles great (no matter how long you let it) and starts without smoke.....also when the truck hiccups, there is no smoke out tailpipe.....hell you stuff it and it barely smokes!
Scenario 1: Normal Driving.
Acceleration steady up to about 40-50MPH. No kicking, no nothing, runs beautiful. Get into OD, engine RPM about 1450-1600. Truck will drive steady at this speed for about 3-7 seconds, then you start to feel the loss of power and the subtle bucking of the truck. If the accelerator is depressed, you notice a 1-2 second pause, then the truck jumps to life and will accelerate flawlessly for as long as you want it to.
Scenario 2: 3rd vs.OD test.
Driving 40MPH, 1500RPM.
Shift truck manually into 3rd. Engine RPM 2000. Truck will hum like it is suppossed to and have zero issue for again, 3-7 seconds. Then you feel a drastic loss of power, and if the accelerator is left untouched, truck will drop 300-500RPM and not run quite right. If the accelerator is depressed once again, there is a slight delay, and then the truck jumps to life and truck will accelerate up to 2500+ RPM no problem.
I know it seems weird.....it only seems to happen UNDER 2000RPM and only when the truck either just shifted gears, and is in the lower RPM range for that gear....and there is a few second delay between the shift/coasting and the problem.
---AutoMerged DoublePost---
and i checked the lift pump.....you can hear it click on and run when truck is glowed, and when its idling you can feel it running.
Truck idles great (no matter how long you let it) and starts without smoke.....also when the truck hiccups, there is no smoke out tailpipe.....hell you stuff it and it barely smokes!
Last edited by sweetguardian001; 01-18-2012 at 07:49 PM. Reason: Automerged Doublepost
