Still working on wiring. Got most of the Ex wiring wired back into the 12. Just have rear wiper, 12v outlet on one side, power for the rear heater/ac fan. Mounted the extra fuse box for those items and all the add accessories. All the DVD players, back up lights, will be coming from the fuse box. It has a hot lead right from the battery 125 amps, and grounding lead to the body and spots to hook up grounds. It's mound underneath the dash right next to where the wiring harness leaves threw the fire wall.
---AutoMerged DoublePost---
Took my extra fuse box back out so I could split the fuse in half. So I have 6 hot at all times and 6 with hot in the key on position. Had to do this with a relay. I also wired in some more stuff.
Back of fuse panel opened up.
---AutoMerged DoublePost---
Took my extra fuse box back out so I could split the fuse in half. So I have 6 hot at all times and 6 with hot in the key on position. Had to do this with a relay. I also wired in some more stuff.
Back of fuse panel opened up.
Last edited by NorthCentral Customs; 02-04-2014 at 09:19 PM. Reason: Automerged Doublepost
#22
Still working on interior wiring. Today I wired the dvd players, one in the drivers head rest, one the passenger headrest and one roof mounted for the third row. They all have to be able to watch the same movie from the big DVD. Also wired for dual usb charging ports. One for the front seats, one for the second seats, one on each side of the third row seat and one in back by 12v outlet. All wired together on one circuit. Put the speakers in from the 12 and wired them. Tomorrow run all the wiring for the 6 seat heaters for the second and third row.
12 on top
---AutoMerged DoublePost---
Pretty much all wrapped up with the interior wiring. Wired the heated seats and started cleaning all the wire mess up.
Set heaters wires
12 on top
---AutoMerged DoublePost---
Pretty much all wrapped up with the interior wiring. Wired the heated seats and started cleaning all the wire mess up.
Set heaters wires
