Timing???
#1
#2
#3
#4
#6
First off, fill out your sig so we can see what you got! Second, do you have gauges?
Now take the afc housing off and remove the fuel plate, the plate is under two flat head screws. The afc housing is held on by 4 bolts and one on the back side you can just back off to get the afc out. One is a breakoff bolt...It can be a really headache to get out but if the have that done already I wont describe that. There will also be a boost line attached on the afc housing and that is easy to take off.
The afc arm will be attached inside of the afc housing you took off...now take the (I think its a 8mm or possible a 10mm) bolt out, and take the little shaft out that was held in there by the bolt and the afc arm will just fall out. The little shaft is in there pretty tight so you might have to use a screw driver to work it out. put the shaft and 8mm bolt back in and the afc housing back on, connect the boost line back on, and you will be good!!! It will add a lot of black smoke if you want it, but also add milage if you take it easy!!!
You can also look it up on utube and there is a good video on there or also look up New England Turbo Diesel Power and they have pics of the afc arm and fuel plate.
I am no teacher but thats the best I can do!!!
Now take the afc housing off and remove the fuel plate, the plate is under two flat head screws. The afc housing is held on by 4 bolts and one on the back side you can just back off to get the afc out. One is a breakoff bolt...It can be a really headache to get out but if the have that done already I wont describe that. There will also be a boost line attached on the afc housing and that is easy to take off.
The afc arm will be attached inside of the afc housing you took off...now take the (I think its a 8mm or possible a 10mm) bolt out, and take the little shaft out that was held in there by the bolt and the afc arm will just fall out. The little shaft is in there pretty tight so you might have to use a screw driver to work it out. put the shaft and 8mm bolt back in and the afc housing back on, connect the boost line back on, and you will be good!!! It will add a lot of black smoke if you want it, but also add milage if you take it easy!!!
You can also look it up on utube and there is a good video on there or also look up New England Turbo Diesel Power and they have pics of the afc arm and fuel plate.
I am no teacher but thats the best I can do!!!
#7
No its not very easy. You need special tools and some skill.
Have you fixed your Killer Dowel Pin? Its a good idea to do the KDP and retime it at the same time as the timing cover will be off.
A How to: TSB 18-10-94 Rev. A
#8
Dont mean to steal the thread... Is there any downsides to adjusting the timing? One thing in life I have found is nothings 100% perfect and everything has to have a downside...
A diesel freak of mine said that it risks the pistons....was he talking the plungers in the p7100 or the engine pistons?
A diesel freak of mine said that it risks the pistons....was he talking the plungers in the p7100 or the engine pistons?
